MIL-HDBK-1036A

1 + 1 MODULE, INTERIOR ACCESS

Requirement

Building Gross Area Per Module

Criteria

66 SQM maximum

(70 High-Rise)

Illustration

Notes

At bed headwall, provide a ganged outlet containing 3 electrical outlets and 1 telephone modular jack.

At wall opposite bed, provide ganged outlet containing 3 electrical outlets and 1 television/LAN outlet.

Locate HVAC control in common area of module.

Figure 1

(1+1) Module (Interior Access)
