MIL-HDBK-1036A

2 + 2 MODULE, INTERIOR ACCESS

Requirement	Criteria	Illustration
Building Gross Area Per Module	79 SQM maximum	Illustration
Gross Area Per Module	62 SQM	61.9 SQM
Net Sleeping Area	8.35 SQM/Person	8.35 SQM
Navy Personnel, Grades E1-E4	2 Persons Per Bedroom	2 Persons Per Bedroom
Marine Personnel, Grades E1-E3	2 Persons Per Bedroom	2 Persons Per Bedroom

Notes:

At Each bed head, provide a ganged outlet containing 3 electrical outlets and 1 telephone modular jack.

At wall opposite bed, provide ganged outlets each containing 3 electrical outlets and 1 television/LAN

outlet.

For high rise construction, building gross area per module may be up to 83 SQM maximum.

Figure 5

(2+2) Module (Interior Access)
