MIL-HDBK-1036A

1 + 1 MODULE, EXTERIOR ACCESS

Requirement	Criteria	Illustration
Building Gross Area Per Module	66 SQM maximum
	(70 High-Rise)
Gross Area Per Module Net Sleeping Area Navy Personnel, Grades E1-E4 Navy Personnel, Grades E5-E9	46 SQM 11 SQM/Person 2 Persons Per Module 1 Person Per Module	46 SQM 11 SQM 2 Persons Per Module Change 1 B/R to Living

Notes

At bed headwall, provide a ganged outlet containing 3 electrical outlets and 1 telephone modular jack.

At wall opposite bed, provide ganged outlet containing 3 electrical outlets and 1 television/LAN

outlet.

Locate HVAC control in common area of module.

Figure 2

(1+1) Module (Exterior Access)
