MIL-HDBK-1036A

2 + 2 PLAN FOR RENOVATION OF EXISTING CONSTRUCTION

Requirements	Criteria	Illustration
Building Gross Area Per Module	79 SQM maximum
Gross Area Per Module	46 SQM
Net Sleeping Area	8.35 SQM/Person	8.35 SQM
Navy Personnel, Grades E1-E4	2 Persons Per Bedroom	2 Persons Per Bedroom
Navy Personnel, Grades E5-E9	1 Person Per Bedroom	Not Illustrated

Notes:

At each bed head location, provide a ganged outlet containing 3 electrical outlets and 1 telephone modular jack

At wall opposite each bed, provide ganged outlets each containing 3 electrical outlets and 1 television/LAN outlet.

For high rise construction, building gross area per module may be up to 83 SQM maximum.

Figure 6

(2+2) Plan for Renovation of Existing Construction
