MIL-HDBK-1036A

2 + 0 MODULE, EXTERIOR ACCESS (Containing 2 Apartments)

Requirement	Criteria	Illustration
Building Gross Area Per Module	85 SQM
Gross Area Per Module	59 SQM	59 SQM
Net Sleeping Area	8.35 SQM/Person	8.35 SQM
Navy Personnel, Grades E1-E4	2 Persons Per Bedroom	2 Persons Per Bedroom
Marine Personnel, Grades E1-E3	2 Persons Per Bedroom	2 Persons Per Bedroom

Notes:

At each bed head location, provide a ganged outlet containing 3 electrical outlets and 1 telephone modular jack.

At wall opposite each bed, provide ganged outlets each containing 3 electrical outlets and 1 television/LAN outlet.

Figure 7

(2+0) Module (Exterior Access)
